Version 5 of The CB&Q in Wyoming Part II

No Rich, Mike has it just about right! :grin:

12 January 2025

As we rolled into December I kept going on roadbed in Powell:

And then I extended the mainline through town…

And out the west end of town into the curve towards Vocation and Cody.

I ordered a couple of bundles of ME Code 55 HO track from Iron Planet Hobbies, and went ahead with wiring the track I had in place. This barrier strip will provide feeders to the track just beyond Powell (the shot of the barrier strip that powers Powell itself came out blurry):

I was out of town for a week attending a wedding in New Jersey, and when I got back I came down with Covid (from one of the other wedding guests). The track showed up Christmas Eve, but it was the 27th before I felt good enough to go down to the train room. When I opened the package from Iron Plant I got a bit of a surprise - N Scale track!

I double-checked the invoice, and sure enough I had ordered HO. A call to Iron Planet netted me a return shipping label, but because I was recovering from Covid it was January 2nd before I could out and send the track back. Storms and what-not delayed the delivery (and their shipment of the correct track). I’m supposed to get the track this coming Wednesday. With that I’ll be able to put in the two remaining sidings in Powell.

The other thing I did in December was renumber a “new” Proto 2000 2-10-2 from 6302, which I already have one of, to 6309. I was surprised how much time it took to remove the old number - about twice the time it takes to remove numbers from BLI locomotives.
But I got it done finally, putting the protective flat finish on the decals after I returned from NJ (I’d applied all the decals before I went). After lubing and tuning up the mechanism it went onto the layout:

The last few days I’ve been trying to renumber a set of hoppers I bought off ebay. I posted another thread about removing the letters without damaging the paint. I tried Mr. Color Thinner, which is what Accurail recommends on their website, and it took off the lettering for sure, plus the underlying paint!

I had some of the renumber decals for a couple different sets of cars on hand from earlier projects, and it turned out that the set for CNW hoppers (set number 2582 if anyone is interested) were a close match for the color on these C&S cars. The numbers aren’t an exact match, but they’re close enough, so today I finished renumbering the entire 7-car set. Here’s one of the “finished” cars:

In a couple days I’ll brush on some Micro Sol to make the decals settle down as much as possible, then the next day I’ll brush on some gloss finish to seal the decals before I start weathering. After I apply the black wash, my first weathering step, I’ll Dullcoat the decals then move on to the chalks.

And with that layout construction reports are all current! There won’t be this rapid-fire status reporting from this point on - depending on how work on the layout goes I’ll post every few weeks.

5 Likes

Incredible work Mark! I hope to someday have a layout half as well worked on as your own! Just a thought as I was reading - if you’re planning on doing any more work removing factory lettering/graphics, I’ve had good success soaking paper towel in Micro Sol, letting it sit on the graphics for 20-30 minutes, then gently rubbing with a pencil eraser rather than a brass brush - somewhat less prone to scratching the equipment! Subscribing to both the thread here to follow progress and to your YouTube channel! Thanks so much for sharing, and awesome work!

3 Likes

Usual amazing standard of work, Mark. How do you keep on going?
Well done.

David

Yes, it is an amazing layout, and Mark will surely set a new endurance record.

Rich

Hi David,

Thanks for the compliment! The layout is actually just a Lionel 4X8. I’m just really good with Photoshop! :grin:

3 Likes

So, you’re finally leveling with your adoring public, eh Mark? :sunglasses:

4 Likes

I posted layout update video 63 today…

6 Likes

Another very enjoyable video.

And, Mark, you look mah-vel-us.

Rich

Now you’re beginning to worry me, Rich!

2 Likes

It’s the shirt, Mark.

It’s always the shirt! :joy:

Rich

Bad Language by Bear, on Flickr

3 Likes

Ahh, nuts, now I have to watch that entire 25-minute video once again to see what you are referring to, Bear. Oh well, a least I get to see Mark’s shirt again, LOL.

Rich

Mark, as always, I loved the video. Strange seeing those locomotives, but a lot of fun.

3 Likes

Thanks for all the kind words, everyone!

9 February 2025

After a bit more work I managed to get the hoppers finished. Here are five of them on the layout:


I added the last two at the end of January.

In mid-January I finally got the track I ordered. It was stuffed into a mailing tube that was a bit too short, which resulted in some slight damage to the ends of a few of the sticks of track, and the entire batch was scrunched up when it was stuffed into the tube. Here’s how it looked when I took it out:


It actually looks worse than it appears in this photo. I am able to straighten it out as I use it, though, so not much loss.

My sidings on the Cody branch (which includes Powell) are all code 55, so I wasn’t able to work on Powell until I got this track. Here, on January 20th, I’ve laid the center siding for the town:

And on the 21st I added the final siding - a short one adjacent to the sugar beet dump (which will mostly be in the aisleway).

That siding is just long enough for three beet hoppers to sit in the clear:

I spent a couple days wiring and testing the new track in Powell. Everything seems okay, so I moved on to the Doodlebug, which was not running real well at the last operating session.
On January 23rd I pulled the bug apart and removed the powered wheels. I expected to find cracked gears, and I wasn’t disappointed.


Both drive axles had cracked gears. I ordered replacement gears (at an obscene price!) from NWSL and put the Doodlebug aside for a couple weeks.

The new gears arrived a few days later. On February 6th I got back to it. With the help of my NWSL wheel and gear puller I was able to easily swap out the old gears for the new ones. Here I’m set up to pull the first wheel:

Everything went back together okay (a miracle considering what a pile of crap the entire mechanism really is), but when I test ran the bug, the drive train was screaming like a banshee! It ran okay, but it emitted an almost constant shrieking noise.

The next day I tore the entire gearbox apart.

I don’t know how this thing ever ran at all! The gearbox was absolutely packed with grease. There was enough in there to lubricate a couple dozen locomotives. When I pulled the box halves apart there was a perfect impression of the gears on one side, and the other half, in this shot, was nearly as bad:

Must have taken me the better part of an hour to clean it all up:

Then I lubed all the bearings with Labelle 108 while reassembling the gearbox, and finally added dabs of Labelle 106 grease to the worm and gears.
It took me most of the day to get the Doodlebug back together (it really is a pile of garbage underneath the shell - up to this point I always had a good opinion of Bachmann’s Spectrum line. Not so much now). But finally it was done and I got it back on the track for another test run.

It still sounds a bit like it’s grinding coffee beans, but it’s quieter than it’s ever been. And it runs great. I wish I’d checked the current draw before I started - with all that half-petrified grease gone, I’ll be it pulls a lot less current now than it did before.

While I was waiting for the gears from NWSL I pulled out the SD9 I bought from ebay and got started with decoder installation. I’d bought a non-sound (diesels sound like white noise to me) TCS decoder with keep-alive and was ready to install it.

There was nowhere to put it! Nearly all the space in the shell is filled with weight! Because the decoder has the keep-alive it’s pretty thick. I needed to trim away some of the weight to make room for it over the front truck. In this shot you can see where I marked the weight for trimming:

Using mostly just a hacksaw I was able to cut away the necessary volume. I half expected I’d break the weight cutting it this way, but I didn’t (it was a good day!).
While I had the loco disassembled anyway I pulled both trucks and removed the bottom cover to check the gears. No cracks!

Like the Doodlebug, the SD9 was way over lubricated, this time just with oil. I cleaned it off as best I could and relubricated everything. After reassembly I installed the decoder:


You’d almost think I knew what I was doing, wouldn’t you? Sheer dumb luck is what it was.

After that it went on the track. Ran really well. I just wish the steamers were this easy.
All in all it doesn’t look too bad - for a diseasel:


Still to do is install the steam generator details on the forward hood.

I bought a similar SD7 right after I bought the SD9. I’m waiting for a decoder for it to arrive. These will be consisted together and put to work hauling max-length trains up the helix from east staging. The 2-8-2 Mikados and even the 2-10-2 Santa Fe’s aren’t quite up to that task.

I wasn’t quite done yet. When I was running a 2-10-2 past the west Casper switch it derailed. Every time. The front driver set would climb the outside rail, and so did the front truck on the tender. Everything else goes through there fine, but not the Santa Fe’s.

There was no kink at the rail joiners:


and the railheads felt fine to my fingers. I checked track gauge and it was okay too. I took a bunch of pictures along the railheads looking for anything out of whack.

I ran a 2-10-2 through the area very slowly and videoed the wheels close-up at 60 frames per second. I blew up the video on my computer and ran it at one quarter speed. I could watch the driver and tender truck climb right up onto the railhead and drop off.
Finally I concluded that the track just past the switch points had just enough of a drop in the outside rail that the 2-10-2’s front driver would rise high enough for the flange to clear the railhead, while nothing with a shorter wheelbase would. So I put a .010 shim under the track just past the points and leading into the curve:


The 2-10-2’s now roll through with no issues. I’m going to leave this like this for a couple of operating sessions to make sure the trouble really is cured, then I’ll trim the shim to the edge of the ties and re-ballast.

And there we are. Now I’m going to go and do something simple, like build a freight car kit.

7 Likes

@Pruitt wow, what an update. You’ve been very busy.

2 Likes

Looks great! What a empire!

Well done, Mark. Sometimes that is what you have to do to solve the problem. Get up close and personal. More than once, I have solved a track problem by getting my eyes right down at track level.

Rich

1 Like

Mark, that black Every Where West paint scheme is my favorite of all CBQ/BN schemes.

Regards, Chris

1 Like

Truly excellent work as always Mark! Thanks for the update!! Generally, at least in my experience, Spectrum tends to be decent, with the major exception being that bug - that thing really is just a complete nightmare lol. And I sympathize with your working to find a spot for that decoder - thats every other install for me down in N scale! Thanks for sharing!

2 Likes
